Product Details:

Place of Origin: China
Brand Name: Theodoor
Certification: ISO 9001, ISO14001, CE
Model Number: FM-35**-L/Y S5

Payment & Shipping Terms:

Minimum Order Quantity: 50pcs
Price: negotiation
Packaging Details: Corrugated carton
Delivery Time: 25 working days after received the payment
Payment Terms: T/T or L/C at sight
Supply Ability: 15,000pcs per month
Detailed Product Description
Product Name: Fashion Wind S5 Air Curtain Application: For Door Entryway Of Shop, Hotel, Restaurant, Store...
Supplied: 120v- 50/60Hz Or 220v-50/60Hz Type: Centrifugal Air
Length: 0.9m, 1m, 1.2m, 1.5m, 1.8m, 2m Color: White, Silver, Red, Brown
Air Speed: 13-16m/s, 16-20m/s Standard: CCC, CE
Control: Remote Control
High Light:

air curtain fan

,

air curtains for restaurants

S5 Commercial Air Curtain For Shop, restaurant, hotel...

Feature:

New fashion specialty designing, unique curve arc-shape, full aluminum body, won’t be rusty and discoloration;
The body is without visible screw, elegant appearance;
Adopting high-performance motor, safe and reliable; using designed centrifugal turbine with strong wind;
Adopting updated remote control with high and low speeds operation;
There are selectable four colors: white, silver, brown, red;
Suitable for installation in luxury hotel, supermarket chains, large stadiums and airport terminals and other entrances of high-grade places etc;
Installation height: 3-4m

Specifications:



Model

Size
(mm)

Volt./ Freq.

Input  power(W)

Air flow
(m3/h)

Air speed
(m/s)

Noise
(dB)

N.W (kg)

Hi

Lo

Hi

Lo

Hi

Lo

FM-3509-L/Y S5

900x220x240

220v/50Hz

230

200

1100

600

13-16

52

49

13.5

FM-3510-L/Y S5

1000x220x240

250

220

1200

900

52

49

14

FM-3512-L/Y S5

1200x220x240

290

260

1500

1200

53

50

16

FM-3515-L/Y S5

1500x220x240

380

350

1900

1500

55

53

20.5

FM-3518-L/Y S5

1800x220x240

450

420

2280

1800

57

54

24

FM-3520-L/Y S5

2000x220x240

470

440

2520

2100

28

56

27.5

FM-4009-L/Y S5

900x220x240

220v/50Hz

300

270

1400

1000

16-20

57

54

13.5

FM-4010-L/Y S5

1000x220x240

320

290

1550

1100

57

54

14

FM-4012-L/Y S5

1200x220x240

400

370

1900

1500

58

55

16

FM-4015-L/Y S5

1500x220x240

500

470

2300

1900

61

58

20.5

FM-4018-L/Y S5

1800x220x240

620

590

3255

2855

63

61

24

FM-4020-L/Y S5

2000x220x240

620

590

3255

2855

64

62

27






















































Theodoor Air Curtain Keeping Indoor Air Quality For Air Conditioning Room Saving AC Energy 0

Theodoor Air Curtain Keeping Indoor Air Quality For Air Conditioning Room Saving AC Energy 1

Theodoor Air Curtain Keeping Indoor Air Quality For Air Conditioning Room Saving AC Energy 2



What is Air Curtain?



Theodoor Air curtain is installed above the entryway of store, restaurant, hotel...etc. It can effectively isolate convection indoor and outdoor and keep temperature and humidity. Especially used in the location with air conditioner to keep indoor environment and save energy of refrigeration equipment. In addition, Air Curtain can prevent the invasion of dust, pest and harmful fumes from outside. In this way, a comfortable indoor climate is maintained.





Applications: door entrance



Business Organizations Supermarket, largescale shopping malls, chain shops, department store, star-rated hotels, restaurants;
Public Places

subway, airports, stations, bookstores, exhibition halls, stadiums, museums,

commercial buildings, hospital;

Entertainments Movie theaters, clubs, bars, cafes, Internet bars, beauty shops.



Company Information



PRECISION PRODUCTION

Founded in 2002, Theodoor is located in Guangzhou innovation and development new areaSino-Singapore Knowledge City (SSGKC) with an area of 30,000 square meters. We have modern production workshop, applying the most advanced industrial equipments and detecting instruments to provide product manufacturing precision and stability of extremely reliable guarantee. Theodoor has full series products which meet different customized demand in different countries or areas.



INNOVATION TECHNOLOGY

With consecutive creation and innovation, Theodoor has built up national standard environmental simulation laboratory as well as air curtain long-time running laboratory. What’s more, Theodoor has accessed national invention and other patents more than 80 items, leading the quality and performance of product upgrading in the industry. Theodoor and the products had passed ISO9001, ISO14001, CCC, CE, CB, ROHS, ERP, UL, SASO, INMETRO and SAA certifications etc.



Theodoor Air Curtain Keeping Indoor Air Quality For Air Conditioning Room Saving AC Energy 3

Theodoor Air Curtain Keeping Indoor Air Quality For Air Conditioning Room Saving AC Energy 4



Why choose Theodoor Air Curtain?



Quality: High quality performance, more than 17 years manufacturing.

Design: Fashion and utility. More than 100 models air curtain, suitable for different environments.

Reliability: Lifetime testing lab in the factory. Enable long life time operation, continuous working 5000 hours without default.

Engineer: Professional R&D and engineer teams focus on Air curtains.

Machinery & technology: Advanced mould machines and equipments ensure products performance and reliability.

Materials and Quality: At every stage, from raw materials to the end products we insist on results: safety, efficiency, energy conservation and environmental protection, and our rigorous testing ensures that we reach standards higher than similar products. We want consumers to depend on the precision and reliability of our Air Curtain machinery.

Quality control: 100% product performance testing.

Cost saving: We provide long-life and high reliability air curtains with excellent quality and better performance, resulting in increased cost saving.
