Natural Wind Air Curtain FM-12 Series 900-2000mm 230V Wall Mount

100
MOQ
US$99
Price
Natural Wind Air Curtain FM-12 Series 900-2000mm 230V Wall Mount
Features Gallery Product Description Request A Quote
Features
Specifications
Operating Voltage: 230 VAC
Airflow: 2000m³/h
Weight: 13 KG
Fan Type: Cross Flow Type Fan
Available Size: 90,100,120,150,180,200CM
Mounting Height: 2.5--3M
Input Power: 160W To 350W
Air Speed: 9-11M/S
Net Weight: 10 To 18 KG
Size: 900X195X220mm To 2000X195X220mm
Motor Type: Pure Copper High Speed Motor
Control Type: Remote Control Or Switch
Noise Level: Low Noise Operation
Material: Aluminum Cover With ABS
Mounting Type: Wall / Window Mount
Highlight:

Natural Wind air curtain wall mount

,

Compact air curtain 230V

,

FM-12 Series air curtain 900-2000mm
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Theodoor
Payment & Shipping Terms
Product Description
Natural Wind Air Door Curtain FM-12 Series
Wall-mounted cool air fan for door widths from 900mm to 2000mm, designed to maintain stable indoor temperatures while saving energy.
Product Specifications
Attribute Value
Type Natural wind air curtain
Operating Voltage 230 VAC
Mounting Type Wall / Window Mount
Warranty 1 Year
Core Components Warranty 1.5 years
Airflow 2000m³/h
Fan Type Cross flow type fan
Available Sizes 90, 100, 120, 150, 180, 200CM
Control Remote control or switch
Mounting Height 2.5-3M
Weight 13 KG
Key Features
  • Lightweight & fashionable design: Patent arc shape appearance with aluminum cover and high-precision ABS materials
  • Easy operation: Adjustable air deflection vane with two-speed control via remote or key switch
  • Low noise operation: Non-isometric quiet impellers with scientific airflow design
  • Premium materials: Pure copper high-speed motor with stable performance (5000+ hours operation)
  • Energy efficient: Helps maintain indoor temperature while reducing energy costs
Technical Specifications
Model Input Power (W) Air Speed (m/s) Net Weight (kg) Size (mm)
FM-1209T/Y 160W 9-11 10 900×195×220
FM-1210T/Y 180W 9-11 11 1000×195×220
FM-1212T/Y 200W 9-11 12 1200×195×220
FM-1215T/Y 230W 9-11 13.5 1500×195×220
FM-1218T/Y 300W 9-11 17 1800×195×220
FM-1220T/Y 350W 9-11 18 2000×195×220
Natural Wind Air Curtain FM-12 Series 900-2000mm 230V Wall Mount 0 Natural Wind Air Curtain FM-12 Series 900-2000mm 230V Wall Mount 1 Natural Wind Air Curtain FM-12 Series 900-2000mm 230V Wall Mount 2 Natural Wind Air Curtain FM-12 Series 900-2000mm 230V Wall Mount 3
About Air Curtains
Theodoor air curtains are installed above entryways of stores, restaurants, hotels, and other commercial spaces. They effectively isolate indoor and outdoor environments, maintaining temperature and humidity levels while preventing dust, pests, and harmful fumes from entering.
Natural Wind Air Curtain FM-12 Series 900-2000mm 230V Wall Mount 4
Applications
Ideal for door entrances of cafeterias, bakeries, waiting rooms, restaurants, retail shops, stations, and other commercial spaces where temperature control and energy efficiency are important.
Packaging & Shipping
Natural Wind Air Curtain FM-12 Series 900-2000mm 230V Wall Mount 5 Natural Wind Air Curtain FM-12 Series 900-2000mm 230V Wall Mount 6
Our Services
  • OEM and ODM services available
  • Custom label and box design
  • Shipping arrangement
  • After-sales spare parts support
Frequently Asked Questions
What are the main functions of an Air Curtain?
  • Dust-proof and insect prevention
  • Odor isolation
  • Energy saving
  • Comfortable heating
How to select the right air curtain?
Consider these factors when choosing an air curtain:
  • Application requirements
  • Door height and width
  • Outside wind conditions
  • Building static pressure
  • Door structure
  • Ambient temperature
  • Size requirements
  • Design preferences
  • Noise level tolerance
  • Power consumption
Why choose Theodoor Air Curtains?
  • Quality: 18+ years manufacturing experience with high-performance products
  • Design: Fashionable and practical with 100+ models for different environments
  • Reliability: Factory testing ensures 5000+ hours of continuous operation
  • Technology: Advanced equipment and professional R&D team
  • Certifications: ISO9001, ISO14001, CCC, CE, CB, ROHS, and more
  • Quality Control: 100% product performance testing
  • Cost Saving: Long-life, high-reliability design reduces operational costs
For more information or professional consultation, please contact us or visit our website: www.theodoor.com.cn
